Servo piston filling
Stable measurementOne click clear
No dead cornersFill at multiple speeds
Efficient productionVarious sizes
Quick to adjustDiving filling
No overflow
设备细节
Application
Application:Agrochemical,daily chemical,food industry, and medical industry.
Agrichemical filling
Daily chemical filling
Food filling
Daily chemical filling
Agrichemical filling
Daily chemical filling
Food filling
Daily chemical filling
Equipment parameter
Model: | GSP-H12 Pistion Filling Machine | Speed of packing: | 2500 bottles/h |
Material: | 304/316 combine stainless steel with carbon steel | Power: | ≤3.5KW |
Driving method: | Servo transmission | Gas comsumption: | 80L/min |
Arrangement structure: | In-line type | Filling heads: | 12 heads |
Type of filling: | Piston filling | Power supply: | 380V/50HZ |
Filling error: | ≤±2% standard | Size: | 2000x1900x1000mm(lengthxwidthxheight) |
Filling head: | Integral pouring filling head, internally blocked filling nozzle | Weight: | 600KG |
Video
Advantages
1
Diving filling
Servo motor submersible filling, filling without overflow or droplet, parameterized production suitable for various specifications.
2
Servo piston
High precision servo piston cylinder metering control, accurate metering, single head adjustable, multi stage fast production.
3
Convenient cleaning
It is built in cleaning mode and can be quick cleaned with one click cylinder removal, compliant with GMP standards.
